JKLYJ(ABC)cables medium voltage 10kv 10 gauge wire for sale
JKLYJ(ABC) cable
Product Description
JKLYJ(ABC)10kV
Al/XLPE insulation
Power cable : Indoors, cable trunking, outdoors
and burried in the ground, for power stations,
industry and switch gear as well as for urban
supply networks, if mechanical damage is unlikely.
| Normal Cross-section | Approx.OD. | Approx. weight |
| mm² | mm | kg/km |
| 35 | 14.8 | 300.8 |
| 50 | 16.1 | 359.8 |
| 70 | 17.8 | 441.0 |
| 95 | 19.6 | 548.0 |
| 120 | 21.0 | 643.0 |
| 150 | 22.6 | 753.6 |
| 185 | 24.2 | 877.3 |
| 240 | 26.4 | 1061.3 |
| 300 | 28.6 | 1263.7 |
