PVC cable steel-tape armored NH-KVV22
Cable:NH-KVV22
Rated Voltage: 0.6/1kV
Conductor: copper
Insulation:PVC
Outer Sheath: pvc
Standards:IEC60331
Cable types:control cables
Sheath color:black
1,This product is manufactured according to IEC60331.
2,Cable can withstand ac fifty hz and 3000 v, pressing time 5 minutes of high voltage test
3,PVC insulated and sheathed control cable shall be used for the connection of the control, signaling, protection and measurement system of the rated smoke 0.6/1kv.
4,Insulated wire core flooding 1 hours later, the high voltage test not breakdown
5,This product is fit for ac rated voltage 450/750 v (Uo/U) or dc 1000 v and under control, the control circuit and protection circuit and so on.
6,Cable working for long-term the highest temperature is 70 C.
7,Cable working voltage should be not greater than 1.1 times of the rated voltage
8.High temperature resistance:950 º C-1000 º C for 3 hours
| Type | Name |
| KVV | Copper core, PVC insulated, PE sheathed control cable |
| KVVP | Copper core PVC insulated PVC sheathed braided shielding control cable |
| KVV22 | Copper core PVC insulated PVC sheathed steel tape armored control cable |
| KVVR | Copper core PVC insulated PVC sheathed control cable |
| KVVRP | Copper core PVC insulated PVC sheathed edit screen control cable |
| KVVP2 | Copper conductor PVC Insulated and sheathed control cable with steel tape shidld |
| ZCNKVV | Copper conductor PVC Insulated and sheathed flame retardant control cable |
| ZCNKVV22 | Copper conductor PVC Insulated and sheathed flameretardant control cable with steel tape armour |
| KYJV | Copper core PVC,PE,XLPE Insulation PVC Sheath cotrol power cable |
| NH-KVV22 | Copper Conductor Fire-resistant material PVC Insulated and PVC Sheathed steel tape armored control cable Cable |
